The TimeWatch TF-2DCW is a compact, dual-door or two-relay networked access controller, built for efficient access management in small offices, residential towers, clinics, and commercial spaces. It allows seamless connection to RFID, fingerprint, and facial recognition terminals, supporting flexible and secure credential-based entry.
Fingerprint
Card
Password
QR
| Specification | Details |
|---|---|
| User Capacity | 1,00,000 |
| Fingerprint Capacity | 10,000 |
| Card Capacity | 100,000 |
| Record Capacity | 500,000 |
| RS-485 | 5 ports. 4 for card readers, and the remaining 1 is for the extension port |
| Wiegand | 4-channel input |
| Network Port | 1 RJ-45, 10 Mbps/100 Mbps self-adaptive |
| Alarm Input | 4 channels; expandable to 8 channels when connected to an external alarm module |
| Alarm Output | 4 channels; expandable to 8 channels when connected to an external alarm module. |
| Alarm Linkage | Yes |
| Exit Button | 2 channels |
| 2 channels | 2 channels |
| Lock Control | 2 channels |
| Anti-pass Back | Yes |
| Tamper Alarm | Yes |
| Duress Alarm | Yes |
| Door Sensor Timeout | Yes |
| Intrusion | Yes |
| Illegal Card Exceeding Threshold | Yes |
| Duress Fingerprint | Yes |
